Description

• Introducing 1st Time In Pakistan Real 6th Gen European Inverter.
• Single Phase Inverter, Supports three phase when installed in Parallel
• 100% Pure Sine Wave Solar Inverter
• Built-in Wi-Fi (10 meter range) & available for Android devices
• Inverter running with battery & without battery
• Built-in Battery equilizations/BMS (Battery Management System)
• Multiple operation modes (On Grid / Of Grid/Hybrid)
• Grid-Tied net metering feature with 100% reverse grid feeding
• Adaptable to main Voltage/generator power
• Conformal coating to prevent from dust and humidity
• New Smart Color Screen LCD with touch buttons
• Built-in anti dust for harsh environment
• Compatible with all kinds of Lithium Batteries (Multiple Parameters)
• Surge Capacity 2* Rated Power for 5 Seconds
• Energy generated record, load record, history information fault record
• Parallel upto 9 Units
• Built-in Dual MPPT parallel based 8500W solar charge controller (160A)
• Smart power management set multiple schedules
• Comunication ports RS232/USB/RS485/CAN
• Zero transfer time
• 98% Real time sharing
• Overload Protection on 150% Load
• High PV input voltage range (120~500 VDC)
• Dual AC Output
• Maximum PV input current 36A
• Builtin Zero export
• European Design and Engineered in Taiwan

  SPECIFICATION
  Rated Power	7000VA/ 6500W
  INPUT
  Voltage	230VAC
  Selectable Voltage Range	90-280VAC (For Home Appliances) / 170-280VAC (For Computer)
  Frequency Range	50Hz/60Hz (Auto Sensing)
  OUTPUT (OFF GRID OPERATION)
  AC Voltage Regulation (Batt.Mode)	230VAC‡10%
  Overload (Line mode)	5a @>150% load; 10s @110%-150% load; 100ms @>200% Load
  Efficiency(Peak)	98%
  Transfer Time	10ms (For Personal Computers); 20ms (For Home Appliances)
  Wave form	Pure Sine Wave
  OUTPUT (GRID-TIE OPERATION)
  Nominal Output Voltage	220/230/240 VAC
  Output Voltage Range	184-264.5 VAC or 195.5 - 253 VAC (Selectable)
  Nominal Output Current	29.54A
  BATTERY
  Battery Voltage	48VDC
  Floating Charge Voltage	54VDC
  Overcharge Protection	63VDC
  SOLAR CHARGER & AC CHARGER
  Solar Charger Type	DUAL MPPT (PARALLEL)
  Maximum PV Array Open Circuit Voltage	500VDC
  MPPT Range @ Operating Voltage	120~450 VDC
  Maximum Solar Charge Current	80A + 80A = 160A
  Maximum PV Input Current	36A
  Nominal PV Voltage	240 VDC
  Maximum AC Charge Current	60A
  Maximum PV Array Power	8500W 98%
  PHYSICAL
  Dimension.D*W*H(mm)	224 x535 x 425 mm
  Net Weight (kgs)	13.5 KGS
  Communication Interface	USB and Rs232
  OPERATING ENVIRONMNET
  Humidity	O to 90% Relative Humidity (Non-condensing)
  Operating Temperature	-10°C to 50°C
  Storage Temperature	-15°C to 60°C
