Supports 802.11ac standard
-
Simultaneous 2.4GHz 300 Mbps and 5GHz 867 Mbps connections for 1200 Mbps of total available bandwidth*
-
4 external antennas and one internal antenna provide stable wireless connections and optimal coverage
-
Easy network management at your fingertips with the TP-Link Tether app
-
MU-MIMO achieves 2X efficiency by communicating with up to 2 devices at once**
-
Beamforming technology concentrates signal to your devices
-
Supports Access Point mode to create a new WiFi access point
| SYSTEM |
|---|
| System Requirements | Microsoft Windows 10/8.1/8/7/Vista/XP/2000/NT/98SE, MAC OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser
Cable or DSL Modem
Subscription with an internet service provider (for internet access) |
|---|
| ENVIRONMENT |
|---|
| Operating Temperature | 0℃~40℃ (32℉ ~104℉) |
|---|
| Storage Temperature | -40℃~70℃ (-40℉ ~158℉) |
|---|
| Operating Humidity | 10%~90% non-condensing |
|---|
| Storage Humidity | 5%~90% non-condensing |
|---|
| PACKAGE CONTENTS |
|---|
| Package Contents | Wireless Router Archer C6
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide |
|---|
| HARDWARE FEATURES |
|---|
| Ports | 4*10/100/1000Mbps LAN Ports, 1*10/100/1000Mbps WAN Port |
|---|
| Button | Reset Button, Power On/Off Button, WPS/Wi-Fi On/Off Button |
|---|
| Power Supply | 12V/1A |
|---|
| Dimensions ( W x D x H ) | 9.1 × 5.7 × 1.4 in (230 × 144 × 35 mm) |
|---|
| Antenna | 4 Fixed External Antennas and 1 Internal Antenna |
|---|
| WIRELESS FEATURES |
|---|
| Wireless Standards | IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz |
|---|
| Frequency | 2.4GHz and 5GHz |
|---|
| Signal Rate | 5GHz: Up to 867Mbps
2.4GHz: Up to 300Mbps |
|---|
| Reception Sensitivity | 5GHz:
11a 6Mbps:-93dBmï¼›11a 54Mbps:-78dBmï¼›
11ac HT20 mcs8:69dBm;11ac HT40 mcs9:-65dBm;
11ac HT80 mcs9:-62dBm;
2.4GHz:
11g 54Mbps:-78dBm;
11n HT20 mcs7:-74dBm;
11n HT40 mcs7:-71dbmï¼› |
|---|
| Transmit Power | CE EIRP: <20dBm(2.4GHz); <23dBm(5GHz)
FCC: <30dBm(2.4GHz & 5GHz) |
|---|
| Wireless Functions | Enable/Disable Wireless Radio, WDS Bridge, WMM,
Wireless Statistics |
|---|
| Wireless Security | 64/128-bit WEP,WPA / WPA2,WPA-PSK/ WPA2-PSK encryption |
|---|
| SOFTWARE FEATURES |
|---|
| WAN Type | Dynamic IP, Static IP, PPPoE, PPTP (Dual Access), L2TP (Dual
Access), BigPond |
|---|
| Management | Access Control, Local Management, Remote Management |
|---|
| DHCP | Server, DHCP Client List, Address Reservation |
|---|
| Port Forwarding | Virtual Server, Port Triggering, UPnP, DMZ |
|---|
| Dynamic DNS | DynDns, NO-IP |
|---|
| Access Control | Parental Controls, Local Management Control, Host List, White List, Black List |
|---|
| Firewall Security | DoS, SPI Firewall, IP and MAC Address Binding |
|---|
| Protocols | IPv4, IPv6 |
|---|
| Guest Network | 2.4GHz guest network, 5GHz guest network |
|---|
| VPN Server | OpenVPN，PPTP VPN |
|---|
