Description

PERFORMANCE

Processor

Intel Core i7-1165G7 (4C / 8T, 2.8 / 4.7GHz, 12MB)

Graphics

Integrated Intel Iris Xe Graphics functions as UHD Graphics

Chipset

Intel SoC Platform

Memory

8GB Soldered DDR4-3200

Memory Slots

One memory soldered to systemboard, one DDR4 SO-DIMM slot, dual-channel capable

Max Memory

Up to 40GB (8GB soldered + 32GB SO-DIMM) DDR4-3200

Storage

Empty M.2 2280 PCIe 4.0×4 SSD Slot + 1TB HDD 5400rpm 2.5″

Storage Support

HDD/SSD mode: up to two drives, 1x HDD + 1x M.2 SSD • 2.5″ HDD up to 2TB • M.2 2280 SSD up to 1TB • M.2 2242 SSD up to 512GB

RAID Preset

Not Support

ExpressCard

Not Support

Card Reader

4-in-1 Card Reader

Optical

None

Audio Chip

High Definition (HD) Audio, Realtek ALC3287 codec

Speakers

Stereo speakers, 2W x2, Dolby Audio

Camera

720p with ThinkShutter

Microphone

2x, Array

Battery

Integrated 45Wh

Max Battery Life

MobileMark 2018: 6 hr (45Wh)

Power Adapter

65W USB-C

DESIGN

Display

15.6″ FHD (1920×1080) IPS 300nits Anti-glare, Touch

Touchscreen

10-point Multi-touch

Color Calibrator

Not Support

Keyboard

Non-backlit, English (UK)

Case Color

Mineral Grey

Surface Treatment

Anodizing sandblasting

Case Material

Aluminium (Top), PC + ABS (Bottom)

Pen

Not Support

Dimensions (WxDxH)

357 x 235 x 18.9 mm (14.1 x 9.25 x 0.74 inches)

Weight

1.7 kg (3.75 lbs)

SOFTWARE

Operating System

None

Bundled Software

None

CONNECTIVITY

Ethernet

100/1000M

WLAN + Bluetooth

11ax, 2×2 + BT5.1

WWAN

Not Support

SIM Card

Not Support

NFC

Not Support

Standard Ports

1x HDMI 1.4b

1x headphone / microphone combo jack (3.5mm)

1x USB-C 3.2 Gen 2 (support data transfer, Power Delivery 3.0 and DisplayPort 1.4)

1x card reader

1x USB 3.2 Gen 1

1x USB 3.2 Gen 1 (Always On)

1x Ethernet (RJ-45)

1x Thunderbolt 4 / USB4 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort 1.4)

Optional Ports (configured)

Not Support
