Specifications
Model	CS-C8C Lite (1080P)
Camera
Image Sensor	1/2.7" Progressive Scan CMOS
Shutter Speed	Self-adaptive shutter
Lens	4mm @ F1.6, view angle: 87° (Horizontal), 105° (Diagonal)
	6mm @ F1.6, view angle: 55° (Horizontal), 66° (Diagonal)
PT Angle	Pan: 352°, Tilt: 95°
Minimum Illumination	0.5 Lux @ (F1.6, AGC ON), 0 Lux with IR (data is obtained from EZVIZ laboratories)
Lens Mount	M12
Day & Night	IR-cut filter with auto switching
DNR	3D DNR
WDR	Digital WDR
Black & White Night Vision	30 m / 100 ft.
Video & Audio
Max Resolution	1920 × 1080
Frame Rate	Max: 30fps; Self-Adaptive during network transmission
Video Compression	H.265 / H.264
H.265 Type	Main Profile
Video Bit Rate	Full HD; Hi-Def; Standard. Adaptive bit rate.
Audio Bit Rate	Self-Adaptive
Max. Bitrate	2Mbps
Network
Wi-Fi Standard	IEEE802.11b, 802.11g, 802.11n
Frequency Range	2.4 GHz ~ 2.4835 GHz
Channel Bandwidth	Supports 20MHz
Security	64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate	11b: 11Mbps,11g :54Mbps,11n :72Mbps
Wi-Fi Pairing	AP pairing
Protocol	EZVIZ Cloud Proprietary Protocol
Interface Protocol	EZVIZ Cloud Proprietary Protocol
Wired Network	RJ45 × 1(10M/100M Adaptive Ethernet Port)
Storage
Local Storage	Micro SD card slot (Max. 256G)
Cloud Storage	EZVIZ Cloud Storage
Function
Smart Alarm	AI-powered human shape detection
Customized Alert Area	Supports
Audio	Supports mic
General Function	Anti-flicker, dual-stream, heart beat, password protection, watermark
General
Operating Conditions	-30°C ~ 60°C(-22°F to 140°F ), humidity 95% or less (non-condensing)
IP Grade	Weatherproof Design
Power Supply	DC 12V / 1A
Power Consumption	MAX. 6 W
Dimensions	158 × 157 × 149 mm (6.22 × 6.18 × 5.87 inch)
Packaging Dimensions	197 × 185 × 205 mm (7.76 × 7.28 × 8.07 inch)
Weight (With Package)	885 g (31.22 oz)
Net Weight	510 g (17.99 oz)
In the box
In the box	Camera (×1)
	Power Adapter (×1)
	Screw Kit (×1)
	Waterproof Kit (×1)
	Drill Template (×1)
	Regulatory Information (×1)
	Quick Start Guide (×1)
